400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h

400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h

Place of Origin:

China

Brand Name:

UT

Contact Us
Request A Quote
Product Details
Max. Capacity:
5 Ton/h
Applicable Industries:
Farms
Showroom Location:
None
Condition:
New
Type:
Chaff Cutter
Voltage:
380V/220V
Dimension(L*W*H):
2620*2140*3390MM
Weight:
2800 Kg
Warranty:
12 Hours
Key Selling Points:
Sustainable
Marketing Type:
Hot Product 2019
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
2 Years
Core Components:
Gearbox, Motor, Engine
After-sales Service Provided:
Engineers Available To Service Machinery Overseas
Raw Material:
Green Or Dry Corn Stalks, Rice Straw And Other Forage Crops
Advantage:
Low Energy Consumption
Motor:
Chinese Famous Brand
Processing Types:
Poultry Feed Line
Key Word:
Baler Package Machine
Function:
Diesel Engine Type
Main Market:
Malaysia Etc
Name:
Silage Corn Straw Package Machine
Item:
Hydraulic Corn Square Hay Balers
Motor:
220v/380v/415v/customzied
Color:
Customzied
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiation
Packaging Details
wooden box
Product Description

Square Silage hydraulic baling machines

Alfalfa Square baling machines Silage Baler Machine In Pakistan Hydraulic Square Hay Balers 400-500kg


Product Description

 pictures of  Alfalfa Square baling machines Silage Baler Machine In Pakistan Hydraulic Square Hay Balers 400-500kg400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 0400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 1

400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 2400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 3

400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 4400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 5400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 6400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 7400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 8Descriptions of the straw hydraulic baler machine Alfalfa Square baling machines Silage Baler Machine In Pakistan Hydraulic Square Hay Balers 400-500kg:



1. A forage baler is a machine that compresses, bundles, and packages crushed corn stover.


2. The machine has the advantages of compact structure, convenient operation, stable and reliable transmission, and flexibility. Widely used in the green storage and dry storage of animal husbandry forage.


3. It can save storage space and prolong the feeding time of green straw. It greatly reduces the transportation and storage costs of feed and reduces the labor intensity of workers.


4. The equipment belongs to the automatic straw hydraulic baler. The equipment completes the whole straw scrap packing through the work of the stroke switch and the four hydraulic cylinders.





400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 9

 400-500kg Capacity Hydraulic Square Hay Balers 2620*2140*3390MM Max. Capacity 5 ton/h 10



Specifications of straw hydraulic baler machine Alfalfa Square baling machines Silage Baler Machine In Pakistan Hydraulic Square Hay Balers 400-500kg :





small hydraulic automatic  baler horizontal compress / press paper baler machine  Configuration

Model

UT-200

UT-180

UT-160

UT-160

UT-120

UT-120

Nominal Push Force(kn)

2000kn

1800kn

1600kn

1200kn

Motor

30kw+18.5kw Hydraulic pump

22kw+15kw Hydraulic pump

22kw+15kw Hydraulic pump

22kw

Compressed Room Size(L*W)mm

2800*1200

2500*1100

2000*1100

1900*900

The compressed room size can be customized

Bales Size

(L*W*H)mm

1700*1100

*1300

1700*1100

*1300

1500*1100*1300

1700*1100*1300

1500*900*1100

1700*900

*1100

The length can be adjusted

Bales Density

More than 400-450kg/m3

Production Efficiency

8-11 bales/hour

Power system

Hydraulic system with high & low pressure combination

System operating parameters

Mode:YCY14-1BPVR140-17

Rated displacement:230ml/r  ;preset pressure:31.5MPa

System pressure

28MPa

Power

Specifications

3PH  380V

Control System

PLC ,Special detection, automatic control, manual button operation

Hydraulic oil grade

46# Harding-wearing hydraulic oil brand





Packaging & Shipping



1.Waterproof packing with the international export standard by 20ft, 40ft, 40hp container.

2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.

3. Or as per customer's requirements.
