Advanced PVC LED Strip Rope Neon Light Extrusion Machine for Manufacturing Plant

Place of Origin:

China

Brand Name:

Request A Quote

Advanced PVC LED Strip Rope Neon Light Extrusion Machine for Manufacturing Plant

Product Details

Condition:

New

Plastic Processed:

PVC

Application:

Wire

Screw Design:

Single-screw

Screw Diameter (mm):

Screw L/D Ratio:

12:1

Screw Speed (rpm):

2956.3 Rpm

Showroom Location:

Saudi Arabia

Voltage:

220/380/415V

Dimension(L*W*H):

As Client Request

Power (kW):

Weight:

5598 KG

Warranty:

More Than 5 Years

Key Selling Points:

High-accuracy

Applicable Industries:

Manufacturing Plant, Machinery Repair Shops

Video Outgoing-inspection:

Provided

Warranty Of Core Components:

4 Years

Core Components:

Bearing, Motor, Pump

Machinery Test Report:

Provided

Name:

LED Rope Light Machine

Raw Material:

Light Strip

Usage:

Light Strip Extruder

Function:

Light Strip Making

After-sales Service Provided:

Video Technical Support

Keywords:

LED Light Rope Extrusion Machines

Material:

Pvc

Machine Type:

LED Light Rope Extrusion

Capacity:

180kg Per Hour LED Light Rope

Other Name:

LED Neon Rope Light Machine

Port:

Qingdao Port, Tianjin Port, Shanghai Port, Ningbo Port

Motor:

220v/380v/415v/customzied

Color:

Customzied

Color:

Customzied

Payment & Shipping Terms

Minimum Order Quantity

Price

Negotiation

Packaging Details

wooden box

Supply Ability

6 Set/Sets per Month

Innovative Cable Coiling Machine for Easy Wire Wrapping and Packing

Get Best Price

75 40 Wire Cable Electric Copper Wire Extrusion Machines for Industry Cable Production

Get Best Price

320mm Coil Outside Diameter Copper Foil Spooler Coiling Machine with 2.2kw Motor Power

Get Best Price

1250mm Wire and Cable Bobbin Laying-Up Machine for Second Hand Wood Drum Stranding

Get Best Price

Contact Now

Product Description

Advanced PVC LED Strip Rope Neon Light Extrusion Machine for Manufacturing Plant 0

Gongyi UT Machinery

WhatsApp/Viber/Phone: 0086-18236968979

Skype: orion.chai

LLED Strip Rope Neon Light Making Extrusion Extruder Machines

Product Description

1. Silicone led rope extruder Applications :

Silica gel extrusion is widely used, according to the categories of pipe, wire, rod Material, silica gel bar,and LED strip light etc.

Advanced PVC LED Strip Rope Neon Light Extrusion Machine for Manufacturing Plant 1

2.Technical parameter:

LED Strip Silicone Extrusion Machine: 1 Units (65mm)

ITEM	SPEC
Screw Diameter	65mm
Screw and Shell Material	38CrMoAl
Compression Ratio	12:1
Thread Specification	Linear thread, not equal to the same distance
Gearbox	Special designed gearbox for silicone extruder
Motor	High Efficiency Variable Frequency Motor
Frequency Converter	High performance vector converter
Maximum Extrusion	>150KG/H
Power	15kw
Rotating Speed	50rpm Max
Dimension	15007001250mm

(1)Tightness pay-off frame.
(2)Plastic extruder:adopt 15kw frequency motor,heating-apparatus,machine head,wire mold
(3)Plastic drying apparatus(heating power4.5kw,drying power0.25kw)
(4)Auto-feeding apparatus(900w,lift 4m)
(5)Heating control cupboard
(6)Cooling channel 8m, circulating water pump.
(7)Level frame
(8)Blower machine.
(9)Printer UT.
(10)Double wheel hauling and reeling machine

Advanced PVC LED Strip Rope Neon Light Extrusion Machine for Manufacturing Plant 2

Advanced PVC LED Strip Rope Neon Light Extrusion Machine for Manufacturing Plant 7

Packaging & Shipping

Shipping and packing:

1.Waterproof packing with the international export standard by 20ft, 40ft, 40hp

container.
2. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.
Advanced PVC LED Strip Rope Neon Light Extrusion Machine for Manufacturing Plant 8

Our Services

Pre-sale:

1. Suggest to client suitable Bare wire diameter, final product capacity.

2. Introduce machine's structure and features in detail, explain the price component;

3. answer client concerned questions.

After-sale:

1. Start production as soon as receiving down payment.

2. Send photos of machine in manufacturing and finished photos to client, for your better learn about the machine's condition.

3. Delivery machine in time, taking photos during loading, so you can "remote monitoring" your goods.

4. Documents and certificate available in time.

5. Manual documents available. Engineer can be sent to client site for installation instruction.
